Input Rated Voltage : | 90VAC~250VAC |
Input Frequency Range: | 47Hz~63Hz |
Efficiency : | 85%(MIN)at Rated Voltage |
Output: | 5~56V MAX 1.5A |
Output power : | MAX 60W |
Ripple and Noise : | <120Mv at full road with 20MHz bandwidth |
Turn On Delay Time: | <3S (AC:110V and full load) |
Safety protection : | over voltage and current protection for power adapter |
Leakage Current: | <5mA |
Operating Temperature: | 0°C----+40°C |
Storage Temperature: | -20°C----+85°C |
Certificate: | CE FCC ROHS etc |
Safety Standard : | EN60950-1 UL60950-1 ESD (EN61000 3-3)
CAS (60950 ITE/TE) FCC Part 15 subpart B Class B
AN/NZS CISPR 22:2006 |
Data connector | RJ45 +Power pins4&5, Power Return pins7&8 |
Futures: | Compliant with Isolation and Channel
Characteristics of IEEE802.3af
Data and Power carried over Ethernet Cable |
Application: | IP Telephones, Wireless Network Access Points, Blue Tooth Access Point IP Print Servers, Security Camera etc… |
Applications
POE power supply is designed for power at an inconvenient place but
needs to use the network function.
For example, in outdoor surveillance systems need to connect the
network, or the power plug is not enough room to use the network
device, by using POE adapter to increase the convenience.
For power supply, we use the four PIN foot of RJ45 connectors to do
power transmission, output voltage and current depends the device
need, the efficiency is up to 80%.
For newoworking,, we use the four PIN foot of RJ45 connecors to do
data transmission, this provides 10/100Base-T network link speed,
in line with IEEE802.3 af specifications.
RoHS compliant manufacturing process, and every product is 100%
gone through the factory burn-in testing to ensure product
reliability.
Besides standard products and samples offering, We also accept
customized services, if you have special requirement, please do not
hesitate to contact us, We will be serve you in the most
professional manner to meet your needs for customized products.
